10D-IO

10D-IO analog current output modules are designed to interface with a wide range of sensors and equipment used in industrial test and measurement applications that accept process current signals.

Each module provides a single channel of 14-bit controlled isolated current output for use in industrial process control applications.

Configurable discrete output pins enable real-time fault monitoring and rapid response, ensuring seamless process flow and fail-safe operation for enhanced reliability and efficiency in industrial environments.

Digital-to-output isolation is rated at a robust 1500Vrms and all field-side outputs are protected against accidental power-line connections up to 40Vrms. These features safeguard measurement and control equipment from the harmful effects of signal noise, transient surges, ground loops, and other industrial hazards.

Over-range up to 10% beyond specified output values are supported with accuracy guaranteed to ±full-scale. All 10D modules are housed in rugged thermoplastic packages and are specified to operate over the industrial temperature range of –40°C to +85°C

BENEFITS

• Small Footprint
• Simplifies Sensor Interface and Signal Conditioning Design
• Reduces System BOM
• Provides Isolation of External Sensors
• Protects Sensitive System Components
• Breaks Ground Loops
• Reduces EMC Concerns

APPLICATIONS

• Signal Conditioning
• PID Process
• Relay Switching
• Motor Control
• Temperature Regulation
• Test and Measurement
• Pump Control
• Industrial Process Control
